Recently we have finished an order of G Fin tube together with plugs & gaskets for a Brazil customer.

Order Details as below:

ITEM 1

Quantity of the tubes: 576 pieces
Tube Material: ASTM A-179
Tube wall Thickness: BWG 11 (Min. Wall Under Groove)
Tube Diameter: OD. 1" (25.40 mm)
Length of the tubes: 9,145 mm
Length finned of the tubes: 9,045 mm
Unfinned end of the each side of the tube: 50 mm
Types of the fins: EMBEDDED "G FIN"
Fin-material: Aluminium 1060
Fin Heigth: 5/8" (15.87 mm)
Fin Diameter: 2 1/4" (57.14 mm)
Fin thickness: 0.40 mm
Number of fins/inch: 11 fins per inch (433 fins per meter)

ITEM 2

Quantity of the Plug: 2376 pieces (Two Part Plug in SA105)

Quantity of the Gasket: 2376 pieces (Material in ASTM A-1008 CS type A

ITEM 3

Quantity of the tubes: 1188 pieces
Tube Material: ASTM A-179
Tube wall Thickness: BWG 12 (Min. Wall Under Groove)
Tube Diameter: OD. 1" (25.40 mm)
Length of the tubes: 11,000 mm
Length finned of the tubes: 10,900 mm
Unfinned end of the each side of the tube: 50 mm
Types of the fins: EMBEDDED "G FIN"
Fin-material: Aluminium 1060
Fin Heigth: 5/8" (15.87 mm)
Fin Diameter: 2 1/4" (57.14 mm)
Fin thickness: 0.40 mm
Number of fins/inch: 11 fins per inch (433 fins per meter)

ITEM 4

Quantity of the tubes: 400 pieces
Tube Material: ASTM A-179
Tube wall Thickness: BWG 12 (Min. Wall Under Groove)
Tube Diameter: OD. 1" (25.40 mm)
Length of the tubes: 12,192 mm
Length finned of the tubes: 12,092 mm
Unfinned end of the each side of the tube: 50 mm
Types of the fins: EMBEDDED "G FIN"
Fin-material: Aluminium 1060
Fin Heigth: 5/8" (15.87 mm)
Fin Diameter: 2 1/4" (57.14 mm)
Fin thickness: 0.40 mm
Number of fins/inch: 11 fins per inch (433 fins per meter)
